Kia Rio: Component Location - Power Windows - Body Electrical System - Kia Rio UB 2012-2021 Service ManualKia Rio: Component Location


1. Driver power window main switch
2. Passenger power window switch
3. Front window motor
4. Rear window motor
5. Rear window switch
