Description
System Overview
The System offers the following features:
-
Human / machine interface through a 1-stage button, for terminal
switching and engine start.
...
Inspection
1.
Connect the GDS on the Data Link Connector (DLC).
2.
Measure the output voltage of the RPS at idle and various engine
speed.
...
ESC Operation Mode
ESC Hydraulic System Diagram
1.
ESC Non-operation : Normal braking.
Solenoid valve
Continuity
Valve
Motor ...
