Kia Rio: Rear Shock Absorber Components - Rear Suspension System - Suspension System - Kia Rio UB 2012-2020 Service ManualKia Rio: Rear Shock Absorber Components




Must completely be tigtened at the curb position of vehicle when assemble shock absorber
1. Dust cover
2. Shock absorber

Components Location
1. Torsion beam axle 2. Shock absorber 3. Coil spring assembly 4. Rear disc ...

Rear Shock Absorber Replacement
1. Remove the rear wheel & tire. Tightening torque : 88.3 ~ 107.9N.m (9.0 ~ 11.0kgf.m, 65.1 ~ 79.6lb-ft) ...
