Kia Rio: Interior

Component Location Index

Engine Room 1. Receiver Drier 2. Condenser 3. Ambient Temperature Sensor 4. Compressor 5. Discharge Hose 6. Suction & Liquid Tube Assembly 7. Service ...

Compressor Oil Specification

1. The HFC-134a system requires synthetic compressor oil (PAG) whereas the R-12 system requires mineral compressor oil. The two oils must never be mixed. ...

See also:

Compressor Components
1. Center Bolt 2. Hub Bolt 3. Hub Assembly 4. Snap Ring 5. Pulley 6. Compressor Assembly 7. Electric Control Valve (ECV) ...

Circuit Diagram
(M/T) (A/T) ...

Front Impact Sensor (FIS) Installation
   • Do not turn the ignition switch ON and do not contact the battery cable while replac ...
